E-Life EPC-415A G2 – Android Panel PC
E-LIFE EPC-415A G2 ANDROID

E-Life EPC-415A G2
Android Panel PC

The E-Life EPC-415A G2 Android Panel PC is designed for modern industrial automation and digital transformation projects, featuring the RK3568 Quad-Core Cortex-A55 2.0 GHz Arm processor, Android 11 OS, and a 15" industrial TFT LCD with Multi-Touch Projected Capacitive technology. Equipped with advanced I/O options (2 x Gigabit Ethernet, 3 x USB 2.0, 1 x USB 3.0/OTG, 2 x RS232/485, 1 x RS232 2-Wire, HDMI output), Wi-Fi, and Bluetooth, it offers rapid integration and reliable field communication. With a rugged aluminum injection chassis, completely fanless architecture, VESA 75 x 75 mounting, CE certification, and a 5-year warranty, the EPC-415A G2 is the ideal choice for businesses seeking a durable, local, and reliable Android Panel PC solution.

⬇ E-Life EPC-415A G2 Android Panel PC Datasheet
PROCESSOR & MEMORY
RK3568 Quad-Core Cortex-A55 2.0 GHz
2GB LPDDR4 RAM / 16GB eMMC
DISPLAY & TOUCH
15" Industrial TFT LCD
1024 x 768, 350 cd/m², Multi-Touch PCAP
CONNECTIVITY & I/O
2 x Gigabit LAN, HDMI
3 x USB 2.0, 1 x USB 3.0/OTG, 2 x RS232/485
DURABILITY & WARRANTY
Aluminum injection chassis, fanless
CE Certified, 5-Year Warranty
E-Life EPC-415A G2 Android Panel PC
E-Life EPC-415A G2 Android Panel PC connectivity and durability
01 FEATURES

Reliable and Local Android Panel PC Solution

Powerful Industrial Platform with Android 11

The E-Life EPC-415A G2 delivers a robust platform for modern industrial applications with Android 11 and the RK3568 processor. It seamlessly runs HMI, SCADA clients, data logging, dashboards, and custom Android apps.

Glove-Friendly Multi-Touch PCAP

The 15" Projected Capacitive screen supports 5-point Multi-Touch and glove-friendly operation. The 4 mm reinforced glass combines high durability and sensitivity, ideal for high-intensity production lines.

Advanced I/O for Rapid Integration

With 2 x Gigabit Ethernet, 4 x USB, and 3 x Serial ports, the EPC-415A G2 ensures fast integration with PLCs and field equipment. HDMI output allows mirroring to a second display for monitoring.

Sleek and Rugged Aluminum Chassis

The durable aluminum injection body and fanless design make it suitable for 24/7 operation in harsh environments. It offers low maintenance and a long product lifecycle, effectively lowering the Total Cost of Ownership (TCO).

Local Manufacturing, Competitive Pricing

Backed by design experience since 2004, the EPC-415A G2 combines local manufacturing power with competitive pricing and high quality. It helps optimize investment costs in digital transformation projects.

Versatile Expansion & Communication

Featuring a TF card slot, Mini-PCIe, M.2 B-Key, and SIM slot, it meets all needs for Wi-Fi, Bluetooth, and cellular connectivity. Dual-band Wi-Fi provides a strong foundation for wireless field integration.

Why Choose EPC-415A G2?

Local, Reliable, and Industrial

Local design and manufacturing, CE certification, a rugged aluminum chassis, and fanless architecture ensure years of reliable operation. A 5-year warranty provides peace of mind for industrial projects.

Ready for Digital Transformation

Android 11 and a powerful Arm processor provide an agile, scalable platform for OEE tracking, data collection, and smart factory terminals, bridgeing the gap between the field and back-office systems.

Modern Design and User Experience

The 15" PCAP screen, sleek aesthetics, and glove support make it an ergonomic solution. Flexible mounting options ensure it fits perfectly into any workstation, cabinet, or production line.

02 USAGE AREAS

Usage Areas of the
EPC-415A G2

Designed for automation, digital transformation, OEE monitoring, data collection, HMI, kiosks, and any industrial application requiring an Android-based terminal.

Usage of EPC-415A G2 in production and automation environments

Industrial Automation & HMI

Serves as an operator panel or machine HMI, communicating directly with PLCs and sensors to provide real-time control.

Digital Transformation & Data Logging

Acts as a bridge for OEE measurements and field data entry, seamlessly integrating production floor data with ERP systems.

Kiosks & Information Terminals

Perfect for factory info boards, visitor greeting kiosks, and indoor wayfinding solutions with its modern design and Android support.

Logistics & Field Applications

Provides a fixed Android terminal for warehouse management and barcode/QR code integration to digitize logistics processes.

DISPLAY & TOUCH

15" Industrial TFT LCD
Glove-Friendly Multi-Touch PCAP

The EPC-415A G2 features a 15" industrial-grade TFT LCD with 1024 x 768 resolution, delivering sharp visuals. 350 cd/m² brightness and a 1000:1 contrast ratio ensure readability in bright indoor environments.

The Projected Capacitive 5-point Multi-Touch screen is compatible with Latex, Nitrile, PVC, and PU gloves, allowing operators to interact with digital interfaces precisely without compromising safety.

15" Industrial TFT LCD
1024 x 768 Resolution
350 cd/m² Brightness
Projected Capacitive Multi-Touch
Glove Support Enabled*
E-Life EPC-415A G2 15-inch touchscreen
E-Life EPC-415A G2 Android Panel PC mounting options
MOUNTING & INTEGRATION

Flexible Mounting Options
Sleek and Rugged Aluminum Chassis

With VESA 75 x 75 holes, optional panel mount kits, and desktop stands, the EPC-415A G2 can be easily positioned on production lines, control cabinets, or walls. Its compact dimensions make it a stable choice for fixed terminals.

The aluminum injection chassis and electrostatic powder coating protect against impacts, vibration, and harsh industrial conditions. The fanless architecture ensures silent operation and low maintenance needs.

VESA 75 x 75 Mounting
Optional Panel Mount Kit
Desktop & Wall Mount Options
Rugged Aluminum Chassis
1
Android Platform
RK3568 Quad-Core, Android 11
2
Connectivity & I/O
LAN, USB, Serial, HDMI
3
Durability & Warranty
Aluminum case, CE, 5 Years
EPC-415A G2 KEY HIGHLIGHTS
Android 11 &
Cortex-A55 Processor
Powered by the RK3568 Quad-Core Cortex-A55 2.0 GHz processor and Android 11 OS, the EPC-415A G2 is designed to run modern industrial Android applications smoothly. It provides a powerful, flexible, and up-to-date software foundation for data collection, HMI, dashboards, and integrated field applications.
E-Life EPC-415A G2 – Technical Specifications
06 Technical Specifications

E-Life EPC-415A G2 Android Panel PC – Technical Specifications Summary

The E-Life EPC-415A G2 Android Panel PC is a locally manufactured solution designed for modern automation and digital transformation projects, featuring an RK3568 Quad-Core Cortex-A55 2.0 GHz Arm processor, Android 11 OS, a 15" industrial TFT LCD screen, and glove-friendly Multi-Touch PCAP technology. With its durable aluminum injection body, advanced I/O ports, CE certification, and 5-year warranty, it offers long-term and reliable operation.

Platform
Model, Processor, Memory, and Storage
  • Model: EPC-415A G2 Android Panel PC
  • CPU: RK3568, Quad-Core Cortex-A55 2.0 GHz – Powerful and energy-efficient Arm-based processor architecture
  • GPU: Mali-G52, support for OpenGL ES 1.1/2.0/3.2, Vulkan 1.0/1.1, OpenCL 2.0 – Compatible with modern graphics APIs
  • RAM: 2 GB LPDDR4 – Optimized memory structure for light to mid-range industrial Android applications
  • Storage: 16 GB eMMC 5.1 – Reliable embedded storage for operating system and applications
  • Operating System: Android 11 – Ready-to-use platform for modern Android-based HMI, data collection, and digital transformation apps
Imaging
Display & Touch Technology
  • Screen Size: 15" industrial-grade TFT LCD
  • Resolution: 1024 × 768 – Ideal for classic 4:3 industrial HMI applications
  • Brightness: 350 cd/m² – Suitable brightness level for indoor and production floor lighting
  • Contrast Ratio: 1000:1 – Sharp and high-contrast imaging
  • Viewing Angle (H/V): 178° / 178° – Widescreen display easily readable from different angles
  • Touch Screen: Projected Capacitive, 5-point Multi-Touch – Fast and precise touch experience
  • Glove Support: Support for use with Latex, Nitrile, PVC, and PU gloves*
I/O Ports
USB, LAN, Serial Ports, and Video Output
  • USB: 3 × USB 2.0, 1 × USB 3.0/OTG – Easy connection for barcode scanners, printers, and peripherals
  • LAN: 2 × Gigabit Ethernet – Fast and redundant network connectivity for industrial grids
  • Serial Ports: 2 × RS232/485, 1 × RS232 2-Wire – Direct communication with PLCs, field devices, and sensors
  • Display Output: 1 × HDMI – Mirroring to external displays, large information boards, or control room monitors
Wireless & Expansion
Wi-Fi, Bluetooth, and Expansion Slots
  • Wi-Fi: IEEE 802.11 b/g/n/ac – Broad standard support for wireless network integration
  • Bluetooth: Optional Bluetooth 4.2, BLE support – For wireless peripherals and short-range communication
  • TF Card Slot: 1 × TF card slot – For external storage or data transfer
  • Mini-PCIe: 1 × Mini-PCIe slot – Expansion possibility for additional wireless modules or special cards
  • M.2 B-Key: 1 × M.2 B-Key slot – Infrastructure for cellular modems or additional expansion cards
  • SIM Slot: 1 × SIM slot – Ready structure for cellular connectivity in mobile communication scenarios
Design
Chassis Structure, Mounting, and Dimensions
  • Chassis: Aluminum injection, electrostatic powder coating – Durable and sleek body suitable for industrial use
  • Mounting: VESA 75 × 75 mounting holes – Easy installation on cabinets, panels, and industrial areas
  • Optional Mounting Accessories: Panel mount kit, desktop stand, and wall mount bracket
  • Dimensions: 340.5 × 282.5 × 64 mm – Compact and balanced design for the 15" segment
  • Weight: 5 kg – Optimized mechanical structure for stable and reliable usage
Power, Environment & Certifications
Power Supply, Operating Conditions, and Warranty
  • Power Supply: 12V / 2A DC adapter – Compatible with common power infrastructures in the field
  • Power Input: 12V DC – Easy integration in industrial panels and control cabinets
  • Operating Temp: 0 ~ 60 °C – Ideal operating range for production lines, control rooms, and factories
  • Certifications: CE – Compliance with European Union standards
  • Warranty: 5 Years – Low Total Cost of Ownership (TCO) for long-term projects
  • Notice: Noya Dijital Dönüşüm Teknolojileri reserves the right to change product specifications without notice.
  • *Glove Note: Glove support is applicable for gloves made of Latex, Nitrile, PVC, and PU materials.
